Send InquiryConcura Medium Flutter
Price 192000.00 INR/ Unit
Concura Medium Flutter Specification
- Color
- Green
- Product Type
- Testing Equipment
- Power
- 220 Volt (v)
- Power Supply
- Electric
- Application
- Industrial
- Machine Weight
- 110 Kilograms (kg)
Concura Medium Flutter Trade Information
- Minimum Order Quantity
- 1 Unit
- Payment Terms
- Letter of Credit at Sight (Sight L/C), Letter of Credit (L/C), Cheque
- Supply Ability
- 20 Units Per Week
- Delivery Time
- 4 Week
About Concura Medium Flutter
DESCRIPTION:
Concura Medium Flutter is used to determine the flat crush resistance / CMT value of a packaging or similar grade of paper. The flat crush resistance / CMT value is the force required to crush the flutes of the corrugated paper, the force being applied perpendicular to a plane tangential to the flutes as per standard testing conditions.
TEST DESCRIPTION:
A rectangular test piece is corrugated between heated corrugated rolls. The flutes are set and held together by a strip of double sided adhesive tape so that a single phased test piece of a corrugated board is obtained to determine the flat crush resistance.
SALIENT FEATURES:
Fluting rolls are heated upto 1760C maintaining a constant temperature by digital / thermostatic temperature controller.
Heater built into fluter roll for a faster and more uniform temperature distribution.
Drive bearings isolated from heat for longer life.
Easy access to fluter rolls for inspection and calibration with easy sample feeding.
Space Saver design minimizes bench space.
TECHNICAL SPECIFICATION:
| Flute Type : | A Flute Rolls |
| Flute Rolls : | Two |
| Revolutions of Flute Rolls : | 4.0 per min |
| Force between Rolls : | Spring loaded force adjustable to 10 Kgf 1 |
| Number of teeth : | 84 |
| Depth of teeth : | 4.75 mm |
| Temperature : | Adjustable and Thermostatically controlled upto 2000C |
| Power Supply : | 440 V,3 Phase 50 Hz |
| APPLICABLE STANDARDS :
| OPTION: Regular/ Deluxe/ Digital Model | ||||||||
|
| |||||||||
Price:
- 50
- 100
- 200
- 250
- 500
- 1000+
