Send InquiryRotary Digester
Price 370000.00 INR/ Number
Rotary Digester Specification
- Equipment Type
- Rotary Digester
- Operate Method
- Manual
- Application
- Pulp and paper industry
- Usage
- Paper pulp cooking
- Capacity
- 25 Ltr
- Control Mode
- Manual
About Rotary Digester
DESCRIPTION:
Rotary Digester is designed for producing pulp from various fibrous materials under specified and control condition under pressure, temperature and time. It produces pulp in a manner similar to a commercial digester.
A stainless steel pressure tested vessels with jacketed heater to raise the required temp. of the cooking media inside and devices to displays the parameter like pressure, temperature and time duration. The vessels attach to a cabinet with control panel and rotate with change of turning of direction to ensure efficient agitation of the cooking media.
APPLICATIONS:
Paper, Paper, Recycled paper
SALIENT FEATURES:
Stainless steel pressure tested vessels.
Electric heating is provided by Microprocessor based temperature
indicator cum controller.
Provided with Temperature Indicator, Pressure indicator, Safety Valve and needle valve.
Rotating Frequency ensures efficient agitation of
the pulp.
TECHNICAL SPECIFICATION:
| Capacity : | 25 Liter |
| Type : | Round Cylindrical |
| Digester Body : | Made of Acid proof steel |
| Auto Clave : | Fabricated from tested boiler plate with inside wiring of stainless steel sheet |
| Raw Material : | 3.0 kg. Wood chip |
| Temp : | 50 250o |
| Max. Pressure : | 15.0 Kg./cm2 |
| Rotation Angle : | 360 o Center |
| Total Power : | 11 KW |
| Motor Rating : | 3 Phase, 440 V, 1/2 HP |
| Read Out : | 3-1/2 Digits |
| Resolving Power : | 0.01 Ph 1MV |
| Measuring Range : | 0.14 Ph 19991999 MV |
| Electrodes : | Glass Combined Electrodes |
| APPLICABLE STANDARDS :
| OPTION:
| ||||||||
|
| |||||||||
Price:
- 50
- 100
- 200
- 250
- 500
- 1000+
