Send InquiryCrush Tester
Price 125000.00 INR/ Unit
Crush Tester Specification
- Application
- Industrial
- Material
- Stainless Steel
- Color
- White
- Voltage
- 220 Volt (v)
- Power Supply
- Electric
- Machine Weight
- 110 Kilograms (kg)
Crush Tester Trade Information
- Minimum Order Quantity
- 1 Set
- Supply Ability
- 20 Sets Per Week
- Delivery Time
- 4 Week
- Main Domestic Market
- All India
About Crush Tester
DESCRIPTION:
Crush Tester is an efficient and easy to use equipment intended for testing paper, corrugated board and its components as well as performing compression tests on small packages. A crush test detects poor adhesive penetration, spotty adhesion and carton board with low bond strength. The bonding strength of glue of selected liners / flutings of a corrugated board are determined by using the PAT test. Sturdy design of the instrument ensures that the parallelism of the plates is maintained for accurate results.
Measuring Unit: Breaking force in Kgf & N.
SALIENT FEATURES:
Complete with memory for retaining peak value, automatic or normal zero setting with Imported Load Cell.
Single push button operation activates an automatic test cycle, determining rapidly the RCT, ECT, PAT and FCT.
RCT, ECT, PAT and FCT all tests are possible through single machine.
Overload protection, Auto Calibration & Digital display.
Changeable peak detection level for different test.
Available in measuring range of 0-100, 0-250 & 0-500 kgf.
Accuracy 1% of measured value.
A reliable, easy to use and cost effective model.
TECHNICAL SPECIFICATION:
| Measuring Results : | Breaking Force in Newtons. |
| Stroke Length : | 76 mm. |
| Deformation Speed : | Calibrated 12.0 mm/min or variable speed. |
| Test Speed / Return Speed : | 5-50 mm/min / 100 mm/min. |
| Plate Size : | 125 X 125 mm. |
| Measuring Range : | 0 - 1000 N. |
| Accuracy : | 1% of reading. |
| Rupture Sensitivity : | 2 - 20 % of the relevant maximum load. |
| Power Consumption : | 200 W. |
| Power Supply : | Single Phase, 220 V, 50 c/s. |
| APPLICABLE STANDARDS : TAPPI T-808, T-809, T-818, T-821, T- 822, T-823, T-824, SCAN P42, SCAN P27, SCAN P34, SCAN P33, SCAN P32, ISO 7263, ISO 3037, ISO 3085, ISO 13820,DIN 53143,DIN 53134, DIN 53149, FEFCO No.8, FEFCO No.6, FEFCO No.11 | OPTION: As Per Customer Requirement | ||||||
| |||||||
Price:
- 50
- 100
- 200
- 250
- 500
- 1000+
